Начало > Продукти > Wireless Router > A2004
- Изключително висока скорост
- Едновременен Dual Band
- Heat-dissipation Design
- Многоточкова безжична мрежа за контрол на достъпа
- Мултифункционален USB 2.0 порт
- VPN(Virtual Private Network) за дистанционен обмен на данни
- Пет гигабитови порта за изключителен трансфер на данни
- Изключителен широколентов контрол с QoS
- Complies with 802.11ac/a/b/g/n standards.
- Simultaneous 2.4GHz 300Mbps and 5GHz 867Mbps.
- Equipped with four high gain antennas.
- Adopts advanced MIMO technology.
- Supports PPPoE, DHCP and Static IP broadband functions.
- Provides five Gigabit Ethernet Ports.
- Provides Multiple SSID and QoS function.
- Provides 64/128-bit WEP, WPA, WPA2 and WPA-Mixed security.
- Connects to secure network easily and fast using WPS.
- Supports IP, MAC, URL filtering and Port Forwarding.
- Supports universal repeater and WDS function.
- Provides a multi-functional USB2.0 port.
- The VPN server can not only protect the privacy of your information, but also simplify network management.
| HARDWARE FEATURES | |
|---|---|
| Interface | 4 *10/100/1000Mbps LAN Ports |
| 1 *10/100/1000Mbps WAN Port | |
| 1 *USB 2.0 Port | |
| Power Supply | 12V DC/2A |
| Button | 1 *WPS Button |
| 1 *RST Button | |
| LED Indicators | 1 *Power, 1 *CPU, 1 *2.4G Wireless, 1 *5G Wireless, 1 *WAN, 4 *LAN, 1*USB |
| Antenna | 2 *5dBi Fixed Antennas(2.4GHz ), 2 *5dBi Fixed Antennas(5GHz ) |
| Dimensions (L x W x H) | 7.2 x 5.3 x 1.0 in. ( 182.3 x 133.8 x 25.9 mm) |
| WIRELESS FEATURES | |
|---|---|
| Standards | IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a |
| RF Frequency | 2.4GHz/5GHz |
| Data Rate | 2.4GHz: Up to 300Mbps |
| 5GHz: Up to 867Mbps | |
| EIRP | 2.4GHz < 20dBm |
| 5GHz < 23dBm | |
| Channels | 2.4GHz: 1-11 (North America), 1-13 (General Europe), 1-14 (Japan) |
| 5GHz: 36~165 | |
| Wireless Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES) |
| Reception Sensitivity - 2.4G: | 11b: <-79dbm? |
| 11g: <-68dbm? | |
| 11n: HT20<-65dbm HT40: <-61dbm | |
| - 5G: | 11a:<-68dbm? |
| 11ac: HT20<-65dbm HT40: <-61dbm HT80: <-51dbm | |
| SOFTWARE FEATURES | |
|---|---|
| WAN Type | PPPoE/DHCP/Static IP |
| Wireless Functions | Multiple SSID, Wireless Bridge, MAC Authentication, |
| WDS, WPS,Wireless Scheduler | |
| NAT / Routing | Port Forwarding, DMZ/Twin IP, Port Trigger |
| Firewall | Internet Access Control: IP/MAC Address filtering |
| Net Detector | |
| Utility | VPN, DDNS, WOL, Host Scan, IPTV |
| Traffic | QoS, Connection Control |
| System | System Log, Admin Setup, Firmware Upgrade, |
| System Time, Config Backup and Restore | |
| USB Storage | FTP Service |
| Samba Service | |
| URL Service | |
| Package Contents | A2004NS Wireless Router *1 |
| Power Adapter *1 | |
| Ethernet Cable *1 | |
| Quick Installation Guide *1 | |
| Environment | Operating Temperature: 0?~40 ? (32 ?~104?) |
| Storage Temperature: -40?~70 ? (-40 ?~158?) | |
| Operating Humidity: 10%~90% non-condensing | |
| Storage Humidity: 5%~90% non-condensing | |
Цялото съдържание на този сайт е приложимо само за модели, които се продават в пазари, извън континенталната част на Китай, Тайван и Южна Корея. Който и да е модел, закупен от континенталната част на Китай, Тайван и Южна Корея, може да бъде повреден при обновяване на софтуера от този сайт и не влиза в гаранционното обслужване на продукта.
| Model | Download | Version | Updated |
|---|---|---|---|
| A2004NS-V4 | A2004NS-V4_en_10_022.zip | en_10_022 | 2017-11-30 |
| A2004NS-V1 | A2004NS V1_en_10_022.bin.zip | en_10_022 | 2017-11-25 |
| A2004NS-V1 | A2004NS_en_9_962.zip | en_9_962 | 2017-06-01 |
| A2004NS | TOTOLINK A2004NS-V1_en_9_74.zip | en_9_74 | 2015-07-27 |
| Model | Download | Version | Updated |
|---|---|---|---|
| A2004NS | A2004NS_datasheet_V1.5.pdf | ver1.5 | 2016-07-28 |
| Model | Download | Version | Updated |
|---|---|---|---|
| A2004NS | A2004NS User Manual V1_1.1.zip | ver1.1 | 2014-05-20 |
| Model | Download | Version | Updated |
|---|---|---|---|
| A2004NS | A2004NS QIG V2.0.pdf | ver2.0 | 2016-07-21 |
| Model | Download | Version | Updated |
|---|---|---|---|
| A2004NS | A2004_Photo003_1.jpg | Resolution 1200x1200 | 2014-05-20 |
| A2004NS | A2004_Photo002_1.jpg | Resolution 1200x1200 | 2014-05-20 |
| A2004NS | A2004_Photo001_1.jpg | Resolution 1200x1200 | 2014-05-20 |
